HDS Series Skid Gasoline Belt Drive – HDS-3505-0V6G

3500 PSI | 4.7 GPM | 627cc Vanguard OHV | General Pump

SKU: HDS-3505-0V6G Category:
  • Belt drive triplex piston pump with ceramic plungers
  • Factory preset unloader
  • Performance-proven engine with electric start- battery not included
  • Heavy-duty powder coated steel skid frame
  • Stainless-steel removable front panel for access to pump
  • Stainless-steel coil wrap and control panel
  • 2900-watt generator
  • Three-way ball valve for inlet selection
  • 120V/15-amp auxiliary GFCI outlet
  • Hour meter
  • Adjustable thermostat
  • Adjustable high pressure detergent injector
  • Quick connect nozzles - 0°, 15°, 25°, 40° plus wet steam and fixed detergent nozzle
  • 25° nozzle for wet steam operation
  • 50-foot x 3/8-inch steel wire-braided high pressure hose with quick connects (1/2-inch on HDS-3008 models)
  • Adjustable pressure insulated dual lance with trigger gun
  • Limited engine warranty
  • CSA Certified - US and Canada

Net WT: 750 lb. | Ship WT: 854 lb.

Additional information

Brand

Mi-T-M

PSI

3500

GPM

4.7

Pump Brand

General

Engine

627cc Vanguard OHV

Drive Type

Belt Drive
